The latest Helitronic Tool Studio software for tool grinding now includes integrated functionality for the design, programming and simulation of PCD tool erosion.

Available from Warwick-based Walter Ewag UK Ltd (www.walter-machines.com), the wizard-enabled software is suitable for use on all ‘two-in-one’ Walter Helitronic Power Diamond and Diamond Evolution tool-grinding and erosion machines.

The new software is said to give users a quick and easy route to the selection and real-time simulation of PCD drill, mill and reamer production; it incorporates both the grinding and the eroding operation.

Moreover, after selecting the tool size, geometry, grinding wheel and electrode ‘package’, the system offers a simulation mode where parameters can be easily changed before tool production starts.

Further functionality includes automatic collision control, as well as geometry and parameter selection for individual teeth.
