Stamping a presence in electrification laminations

Posted on 15 Oct 2020 and read 377 times
Stamping a presence in electrification laminationsA Birmingham-based stamping specialist is pressing the button on a £1 million project that will see it develop a new process to support the UK’s acceleration into electrification.

Brandauer, which already produces components for use in more than half of the world’s cars, has secured over £300,000 of funding from the Industrial Strategy Challenge Fund run by UK Research and Innovation to help it set-up a high volume e-machine stack line to produce thin laminates required by the automotive and aerospace sector.

Working in partnership with WMG and supported by Jaguar Land Rover, the 158-year-old manufacturer believes there is an initial £500,000 opportunity it can secure once the methodology is in place — it is anticipated that the market could eventually be worth between £60 to £70 million.

Engineers and academia will be working to create an in-line adhesive dispensing process to support the volume challenge, while the second part will see them work towards the integration of an advanced stamping line capable of creating 0.1mm laminations with very narrow iron bridges.

Brandauer 2Adam Burgoyne, Brandauer new product introduction and quality engineer, said: “This project is a game-changer for our business, but importantly a game-changer for the UK power electronics, machines and drives (PEMD) supply chain and its ability to supply an increasing demand for e-components from tier 1s and car makers.”

“Our laminations business is growing, initially focused on aerospace and defence work. However, the really big opportunity is in electrification and, to put us in that global arena, we need to be able to stamp extremely thin laminations to a high quality and large volume.”

“This is what we’ll be working towards over the next twelve months, bringing in the knowledge of WMG and the guidance of JLR. Taking on a project of this magnitude during Covid-19 is a big challenge and has been made possible thanks to the financial support secured from UK Research and Innovation.”

Brandauer, which developed its own range of nose clips for face masks and a new visor to support the fight against Covid-19, will start by developing its own in-house methodology, transferring expertise from applying lubricant surface coatings to stampings during manufacture.

This will reduce the company’s cycle times, while also improving its productivity and allowing it to grow its capacity by 50%.

The second stage will use the existing design of a rotor/stator stack with 0.2mm laminations as a base, before changing the material thickness to the required 0.1mm. Proving out stamping feasibility and preparing for manufacture will take place, with narrow bridge trials completed to identify the exact production process and the required ‘state of the art’ manufacturing techniques.

Brandauer 1Mr Burgoyne added: “There is a clear market signal, with our sales engineers regularly fielding £10 million enquiries per annum for this capability. This isn’t just about Brandauer though. This is about creating a process and technology that will deliver the UK a vitally important technology, which will not only drive the sector’s growth in electrification but will also support the net carbon 2050 target.”

Brandauer is one of the West Midlands’ best-kept manufacturing secrets, producing millions of high-tolerance metal pressings and stampings every week for customers in the plumbing, automotive, domestic products, electrical, medical and renewables sectors.

It is part of a new manufacturing cluster that has been established to target multi-million-pound electrification opportunities over the next twelve months and includes Alucast, C-MAC SMT, PP Control and Automation and industrial automation specialist Balluff.
