GKN Aerospace in Sweden has successfully delivered the first Intermediate Compressor Case (ICC) to the Rolls-Royce UltraFan engine demonstrator programme.

GKN Aerospace is a Core Partner in Clean Sky 2 and in the Rolls-Royce led UltraFan engine demonstrator programme with responsibility for design and manufacture of the ICC.

The ICC is a structure between compressor cases, which carries the rotor gas loads to the engine casing and thrust mounts. Development, manufacture and testing of the ICC will demonstrate and validate a range of new technologies, including a low-cost and robust sectorised fabrication concept with castings.

This makes use of an innovative welding method based on computer simulations: optimised bleed system aerodynamics and acoustics; shorter aggressive duct design and 3-D printing of attaching parts; and model-based design methods.

UltraFan is Rolls-Royce’s next-generation engine family and aims to offer a 25% improvement in fuel efficiency over the first generation of Trent engines. It features a new engine core architecture and introduces a geared design. The aim is to achieve a full engine ground test during 2022, with flight testing to follow.

Clean Sky 2 is the largest European aeronautics research programme, developing innovative, cutting-edge technology aimed at reducing CO₂ emissions and noise levels produced by aircraft.

Funded by the EU’s Horizon 2020 programme and Europe’s aviation industry, the programme aims to strengthen European aerospace-industry collaboration, global leadership and competitiveness.

Henrik Runnemalm, vice-president of GKN Aerospace’s Global Technology Centre in Sweden, said: “The delivery of the UltraFan engine ICC to Rolls-Royce is a true milestone. It reaffirms the success of the Clean Sky2 collaboration programme and we are excited to have implemented our latest sustainable technologies in the ICC’s development.

“We are extremely proud to be a partner of the Rolls-Royce team and to contribute to this energy efficient aero-engine of the future.”

GKN Aerospace’s development of innovative manufacturing processes for the ICC has been well supported in Sweden thanks to the Vinnova funded IntDemo-project and the Västra Götaland Region.
