New robotic technology that can remotely treat casualties of a natural disaster or a terrorist attack has taken a step closer to entering full production after it recently impressed at a special Ministry of Defence (MoD) event. Researchers from the
University of Sheffield Advanced Manufacturing Research Centre (AMRC),
Sheffield Robotics and Department of Automatic Control and Systems Engineering, successfully put its ‘MediTel’ uncrewed ground vehicle (UGV) through its paces at BattleLab, an initial testing ground for new technologies that can be deployed in hazardous locations.
Design engineers took just nine months to come up with a fully working prototype, leveraging the power of
PTC’s Creo 3D CAD solution to take a standard UGV platform and two robotic arms to create, what many are calling, the next-generation ‘Robo Doctor’. One of three novel telexistence technologies funded through a two-phase £2.3 million innovation competition run by the Defence Security Accelerator (DASA), it can be remotely operated from over one mile away by using virtual reality (VR).
Rigorous testing has seen it successfully perform a critical initial assessment of a dummy casualty, including taking temperature, blood pressure, heart rate checks and even administering pain relief through an ‘auto-injector’. With the positive feedback emanating from its appearance at BattleLab, it is hoped that additional funding can be found to take the prototype forward with the longer-term possibility of scaling up for manufacturing in the UK.
David King (pictured left), head of digital design at the AMRC, said: “Experts from the MoD were amazed that we have come up with a working prototype in just nine months and within the financial budget that was set. That is in no small part because of the long-standing relationship we have with digital transformation specialist PTC and its industry-leading design software.
“We went straight from sketches on paper to quickly designing the first model on Creo, using all its simulation and custom features to get there within a matter of weeks. This included how we mounted the robot on the platform, the mechanical engineering and how we integrated the power systems and arms. There wasn’t lots of time to build practical models, so we had to complete numerous design iterations to get to where we wanted to be and with an operational ‘MediTel’ that could be tested on High Bradfield in the Peak District.”
The MediTel robot can traverse rough terrain and can be used by operators located in a nearby vehicle or in a central hub. A bespoke VR simulator - utilising the HTC Vive Pro - places the user in the heart of the affected area with a 360deg camera giving a bird’s eye view of the patient and the situation. Importantly, engineers at the AMRC believe any medical person can be trained on how to use the technology within 15min.
Elliot Clarke, UKi regional director at PTC, said: “Our software is often at the heart of new innovations, and we are really pleased that it has now helped to create a piece of technology that could save thousands of lives around the world. Creo is the ideal platform if you are looking for agile design, with the real time iterations allowing different team members to input the changes.”
He concluded: “The AMRC team has used Creo on hundreds of different projects and their knowledge of its capabilities and functions were imperative in meeting the nine-month project timeframe. With the positive trial results and all the data in play, it wouldn’t take much to move this forward into real-world production.”
