Camberley-based Bowers Group has launched the new Sylvac Scan S25. Designed to complement the current Sylvac Scan range, including the F60, S145 and Scan 52, the S25 provides a non-contact optical measuring centre to measure small to medium-size cylindrical parts up to 26mm diameter and 200mm in length, while holding parts up to 500mm long.

The new addition to the range also offers easy-to-use high resolution accuracy with impressive results, providing less than 1µm accuracy on diameter and less than 3µm accuracy on length.

Enabling a reduction in inspection time, its comprehensive features include part recognition, reflex-click auto-measure and barcode loading, as well as quick release tooling. Designed for precision, the S25 also features a precision rotary headstock for improved dynamic measurement accuracy.

Bowers Group sales director Martin Hawkins said: “The Sylvac Scan S25 is a fantastic step forward for manufacturers, providing improved accuracy and optical imaging when measuring small turned parts.

“Running the latest Sylvac Reflex-Scan+ software, all static measurements and 2D scans can be speedily obtained within just 3sec, greatly improving productivity. We are delighted to be able to offer this product to market and we are really looking forward to the interest that it will undoubtedly attract.”

The Scan 25 offers dynamic results on a schematic along with analysis all provided on one page, with optional CAD and offline software also available. With a small footprint and a two-man lift, the S25 is perfect for shopfloor operation. In addition to a new built-in user interface, the Scan 25 is automation-ready with a motorised tailstock and additional I/0 connectivity.

To find out more or to book a demonstration, call 01276 469 866, or email .
