Orbex and
Force Technology have been awarded a further contract from the
European Space Agency (ESA) which will enable the two firms to carry out non-destructive, high-energy X-ray inspections of Orbex’s large-scale 3-D printed rocket engines prior to flight, using advanced technology to eliminate any internal flaws.
It will become a key component of the Orbex engine testing regime, reinforcing the reliability and safety credentials of the Orbex ‘Prime’ rocket. The award is the sixth development contract that Orbex has received from ESA. It will work closely with Force Technology on the project – and will become one of the first launch operators to use it.
The X-ray inspection system has already been demonstrated enabling non-destructive inspection of strategic European launch propulsion systems. The technology is the engineering equivalent of a medical CT scanner, revealing the details of the interior of a test item without damaging it in the process.
Orbex is now in its fifth year of its engine testing programme, which has enabled it to generate huge amounts of data and engine testing intelligence. In addition, Orbex has been manufacturing 3-D printed rocket engines since 2018. Its custom-made 3-D printer is the largest high-precision metal 3-D printer in use in Europe, enabling Orbex to produce the world’s largest monobody rocket engines.
The Orbex Prime rocket is currently being tested on the Orbex LP1 launch platform at a facility in Kinloss, Scotland, close to the Orbex headquarters in Forres, where full ‘dress rehearsals’ of launch procedures are taking place.
Prime is a micro-launcher designed to transport small satellites weighing around 150kg to low Earth orbit. Orbex will commence launches from Space Hub Sutherland, the world’s first carbon-neutral spaceport in terms of construction and operation.
X-ray inspection of rocket enginesChris Larmour, Orbex CEO, said: “Orbex is set to be the first launch operator to be able to carry out high-energy X-ray inspection of rocket engines prior to flight, using the unique technologies and IP we are helping to develop as part of our work with ESA.
“As we move towards series production we will use this new capability to give peace of mind to customers and assurance to licensing authorities that we have a fully comprehensive propulsion testing regime in place.”
Lars Vesth, Force Technology COO, said: “Force Technology is constantly pushing the boundaries of what is technically possible, and operating in the space industry has enabled us to be at the forefront of technology innovation over many years.
“In the 1980s Force delivered inspection systems for the US space shuttle; we were awarded our first ESA contract in 2005; and — more recently — have provided technology for the Ariane 6 launcher.
“The recently signed ESA contract with Orbex will create an efficient high-energy X-ray inspection system specifically optimised for the Orbex monobody engines – and Force Technology looks forward to seeing our technology contribute to Orbex progressing to commercial launches.”
