Yamazaki Mazak, the world’s largest manufacturer of CNC machine tools and manufacturing systems, is set to unveil two new laser processing machines for the cutting of tube, pipe and sheet metal — the G-400 NEO and the Optiplex 3015 NEO 15kW — at
EUROBLECH 2022, taking place 25-28 October in Hanover, Germany (Hall 11, Stand D26).
The FG-400 Neo can streamline production and improve performance by running multiple processes in one machine including 3-D cutting, tapping, drilling, chamfering and flow-drilling. The system is ideally suited for large-size tubes and pipes, including round, square, and rectangular cross-sections; as well as H, I, and L beams.
Thanks to the combination of a new 3-D laser head with A axis, B axis and fibre laser technology, it can facilitate the stable machining of complex shapes and highly reflective materials, such as copper and brass. Its four-chuck system provides additional stability by preventing material distortion during processing.
To complement the machine, Mazak has developed a set of quality-of-life functions including part nesting, tool simulation, and a tool path monitor to speed up set-up times to provide continuous production.
Meanwhile, the Optiplex 3015 NEO 15kW is the latest addition to the Optiplex 2-D laser cutting machine series. Thanks to a winning combination of Mazatrol SmoothLx CNC control, MCT3 cutting head, and a wealth of customisation options, the machine delivers highly accurate and precise sheet metal processing. The new model benefits from a high degree of automated features to deliver faster set-up times (up to 95% compared to standard laser machines), including automatic nozzle changing, as well as automatic focus detection and positioning to improve ease of use and optimise piercing performance.
In addition, large front and side access doors improve accessibility to the working area, easing loading and unloading operations. The Nozzle Auto Centring Camera displays the nozzle location on the CNC screen, allowing the operator to make adjustments on the torch, while the nesting feature automatically determines how to arrange the parts for optimal cutting on residual materials.
The Optiplex 3015 Neo 15kW displayed next month at
EuroBLECH (pictured left) will be equipped with the CST 3015 automation system featuring a single tower mounted above the laser pallet changer. It has eight separate pallets each with a load capacity of up to 3,000kg and deploys a suction-based system for the loading of raw material and a dual supported fork set for the unloading of processed workpieces.
As a leading manufacturer of machine tools and laser processing machines, Mazak is strongly committed to reducing its environmental footprint and achieving carbon neutrality by 2030, as highlighted by the company’s ‘Go Green’ initiative.
Both machines on display at
EUROLECH 2022 leverage Mazak’s revolutionary Laser Beam Shaping and Fiber technologies. The cutting quality is achieved by controlling the power density concentration of the laser beam, while a wide range of different materials and thicknesses can be accommodated by adjusting the beam’s diameter and shape.
The Fiber technology can deliver significant cost reductions and energy savings (up to 60% compared to previous models), while providing unsurpassed cutting speed and quality for both thick and thin materials.
