World-first robotic ‘blade walk’ on a wind turbine

Posted on 09 Nov 2020 and read 1158 times
World-first robotic ‘blade walk’ on a wind turbineBladeBUG

The UK has achieved the world’s first blade walk by a robot on an offshore wind turbine, thanks to BladeBUG and the Offshore Renewable Energy (ORE) Catapult. Over two days in mid-October, the six-legged inspect-and-repair robot repeatedly scaled blades at ORE Catapult’s 7MW Levenmouth Demonstration turbine off the coast of Fife.

BladeBUG represents a 30% cost reduction on current blade inspection techniques, which are conducted by rope-access technicians, with a measurable knock-on effect to the levelised cost of energy. For next-generation turbines, ORE Catapult predicts the cost savings could reach as much as 50%.

These costs have traditionally been one of the primary areas of concern for offshore operators, as sea conditions and faster tip speeds can lead to significant blade damage over time.

The robot is being developed under a £1 million collaboration project between BladeBUG and ORE Catapult, part funded by Innovate UK. By the project’s end next year, BladeBUG will be capable of inspecting blade surfaces for emergent cracks and imperfections, transmitting data on their condition back to shore and resurfacing the blades.

BladeBUG had previously demonstrated its abilities on blade sections and the vertical training tower at ORE Catapult’s National Renewable Energy Centre in Blyth. The blade walk at an operational offshore wind turbine has now proven that the robot can conduct lengthy deployments in real-world conditions.

During the demonstration, the robot walked 50m on a vertically positioned blade on the Levenmouth turbine (a length of 84m with the tip reaching 195m above the sea when upright).

The crucial capabilities demonstrated during the trial were: perfect adherence of its vacuum-padded feet to blade surfaces in offshore conditions; ability to navigate the varying curvature of blade surfaces in a variety of scenarios; transmission of data from blade scans and live video feed to technicians demonstrating the BladeBUG’s navigational abilities and placement of feet on changing surfaces

Chris Hill, ORE Catapult’s operational performance director, said: “This is an incredibly significant technology that we know is being keenly watched by the industry as a potential game-changer. It has a clear potential for cutting costs, reducing human offshore deployment and increasing blade lifetimes.

“But, we had yet to see how the robot would perform on a real turbine out at sea. I consider BladeBUG’s first walk at Levenmouth as offshore wind’s ‘moon walk’ – a historic milestone in the industry’s evolution. Robotics are here to stay, and they will be an essential ingredient to operating ever-expanding wind farms, deeper-water sites and faster, bigger turbines in the coming years.”

BladeBUG CEO Chris Cieslak said: “This is such a historic moment for us as a company. It has been so exciting to see results of months of work and development in action and this latest test marks the huge progress we have made.

“In a little over a year we have gone from designing and testing our first prototype, to taking our first tentative steps with our Mark I robot, to now, seeing the BladeBUG robot walk along the blade of an actual offshore wind turbine. We cannot wait to perform further trials and demonstrate the capabilities further offshore.”

The robot is also a key component of the £4.2 million MIMRee project which will demonstrate a fully autonomous inspection and repair mission to an offshore wind farm.

During these trials, BladeBUG will work in collaboration with an autonomous vessel and teams of drones, using a robotic arm to clean and resurface damaged blades. The final MIMRee system technology trials are set to take place in mid-2021.
