New electric rotary stage from norelem

Posted on 23 Oct 2021 and read 997 times
New electric rotary stage from norelemnorelem, the global standard components specialist, has introduced a new electric rotary stage to enable quick, accurate and repeatable positioning. In addition to the company’s manual rotary stages, it now offers positioning rotary stages with coaxial electric drive. Thanks to its digital control system, norelem’s electric range enables angular positions to be precisely and repeatably set to within a hundredth of a millimetre.

With the assured accuracy of norelem’s electric rotary stages, they are ideal for use with handling systems, machine tools or measuring equipment that require motorised adjustment and positioning for consistent outputs.

norelem’s electric positioning rotary stages operate quietly and require little maintenance, and with free programming software available, they can be seamlessly integrated into any motion system.

The pre-tensioned worm gear operates with almost no backlash and the worm shaft bearing offers maximum radial rotation accuracy. Cables can be routed through the large hole in the hollow shaft and with the adjustable positioning ring, the rotation reference point can be set as desired to the position of the mounted component.

Precision is paramount

Marcus Schneck, CEO of norelem, said: “In industry, precision is paramount and can make the difference between success and failure. Our enhanced range of versatile positioning systems are easy to use, saving time and effort during installation, all while providing increased precision in components, with the added benefit of a digital control system.”

Available in size 8 with a gear ratio of 40:1 and size 12 with a gear ratio of 55:1, and a maximum output torque of 1.2Nm or 3Nm, there are 18 versions to choose from. The electric rotary stages can be purchased with or without a motor and/or a control unit and the cable outputs and control orientation can be individually defined. For a long service life, the housing and the turntable are made from anodised aluminium while the hollow shaft is stainless steel.

norelem has also introduced electric positioning rotary stages for high loads, which meet the highest demands for speed and accuracy. In these angular design models, the bearing of the hollow shaft and turntable is affected by means of an axial needle bearing. The rotary stages for high loads are available exclusively in size 12 with gear ratios of 10:1 and 45:1, with an output torque of 3Nm.

Both product families are compatible with the Nema 17 stepper motor and can be combined with all other positioning systems of the same size.

The entire range of rotary stages, alongside an extensive inventory of flexible standard parts and components can be found in norelem’s definitive catalogue, THE BIG GREEN BOOK.
