Since its UK premiere at
MACH 2024, the new Lincoln Electric Linc-Cut Fiber series available in the UK and Ireland from Rochdale-based
Kerf Developments has been expanded further with the introduction of new table dimensions.
Offering linear guides for vastly superior cutting quality, dynamic kinematics, helical drives, rigidity and precision, the Linc-Cut Fiber range is a popular choice for UK manufacturers. Introduced to the UK in 2024, Kerf Developments presented the Lin-Cut Fiber 1530A, a 3m x 1.5m bed machine that the 2040A model complemented, as a larger 2 x 4m variant. It has been expanded at both ends of the size spectrum, with a smaller 1020 drawer model with 1m x 2m added for compact work areas, while a 2m x 6m 2060A model has also been introduced for manufacturers processing larger sheets or multiple parts in a single set-up.
With Lincoln Electric recognised as a world-leading manufacturer of cutting and welding machines, Kerf Developments is proud to represent the brand in the UK and Ireland. Available as a 3kW, 6kW, or 12kW machine, the Linc-Cut Fiber synchronises the laser cutting and axis movements to deliver unsurpassed precision, repeatability, and cutting speed.
Optimum reliabilityThis is assured by an auto-focus laser head with automatic gas and cutting height calibration that delivers optimum repeatability and a compact laser source with a fibre core diameter of 75μm for superior cutting quality.
The new series also incorporates a ‘state of the art’ CNC system that integrates with two surveillance cameras to control and monitor all machine operations. With drawing software and automated nesting, the user-friendly control system includes a database of parameters for all material types and thicknesses. Further innovations include the flycut, fast-cutting, smooth microjoint, frame border, circle centring, and collision avoidance, which enhance productivity and cutting speed.
Advanced technology also permits the contouring of fine parts and the ability to hold and process small parts securely. With rapid axis movements of 110m/min, and positional accuracy of 0.03mm, the Linc-Cut Fiber series demonstrates why it is the future of fibre laser cutting with an impressive number of sales since its UK introduction.
Additional features include a light safety barrier, protective enclosure, fume extraction, two-year warranty, automatic lubrication, air-conditioned electrical cabinet, LED cabin lighting, in-cycle laser head cleaning and double shuttle table. Engineered in Europe with UKCA and CE-certified components, the Lincoln Electric Linc-Cut Fiber range stand out for its quality, precision, productivity and safety attributes.
